| Marketing description |
High-quality professional printer for photos and posters, with a compact, modern design and Wi-Fi connectivity.
A fully integrated solution offering production printing, intelligent features and easy operation. The unobtrusive design is compact thanks to the printer's flat top and rear panels and its small depth. SC-P8500D is built with the Epson PrecisionCore MicroTFP print head and 6-color UltraChrome Pro6 pigment inks, which include grey ink to extend the colour gamut. |
| Product features |
-
Fast and feature-rich
The 2.64-inch PrecisionCore MicroTFP print head prints up to 18 m2/hour with photo quality. The dual roll allows automatic switching between two different types or sizes of media. The automatic take-up reel enables high productivity when printing roll to roll, and the automatic paper loading system makes it easy for inexperienced users to work with media, including sheet and board materials. Wi-Fi to fit almost anywhere.
-
Compact dimensions – universal design
The design of SC-P8500D is both modern and compact. It fits into most working environments thanks to its flat and unobtrusive design.
-
Highly detailed prints every time
The 6-color UltraChrome Pro6 pigment ink set for SC-P8500D – including grey ink – extends the colour gamut and delivers smooth gradients and less grainy texture. This means print quality is on a par with that of other 8-color printers. The PrecisionCore MicroTFP print head, Variable Sized Droplet technology and Nozzle Verification technology together create vivid, high-quality images.
-
Security and management features
SC-P8500D includes advanced IT and security features. In addition, workloads can be managed more efficiently through centralised application tracking.
|
| General data |
| Printer type |
44" wide-format printer – inkjet – colour |
| Printer |
| Inkjet printing technology |
Epson PrecisionCore MicroTFP |
| Supported ink palette (colours) |
6-ink – cyan, magenta, yellow, photo black, matte black, grey |
| Nozzle configuration |
6 x 1600 nozzles |
| Minimum ink droplet size |
3.5 pl |
| Ink cartridge configuration |
6 cartridges (1 each for: cyan, magenta, yellow, grey, photo black, matte black) |
| Ink type |
Epson UltraChrome PRO |
| Built-in devices |
Touchscreen |
| Connectivity technology |
Wireless |
| Interface |
USB 2.0, Gigabit LAN, Wi-Fi(ac) |
| AirPrint support |
Yes |
| Maximum resolution (black and white) |
1200 x 2400 dpi |
| Maximum resolution (colour) |
1200 x 2400 dpi |
| Language emulation |
EPSON ESC/P Raster, HP GL/2, HP RTL, PDF 1.7, PostScript 3 |
| Cutting |
Yes |
| Colour management features |
ICC colour profiles |
| RAM |
| Installed RAM memory (maximum) |
4 GB |
| Media handling |
| Maximum media size |
Roll (111.8 cm) |
| Maximum media size (custom) |
1118 mm |
| Media sizes |
Roll (25.4 cm), Roll (43.1 cm), Roll (60.9 cm), Roll (111.8 cm), Roll (91.4 cm), A0 (841 x 1189 mm), A1 (594 x 841 mm), A2 (420 x 594 mm), A3 (297 x 420 mm), A4 (210 x 297 mm), A5 (148 x 210 mm), B0 (1000 x 1414 mm), JIS B1 (728 x 1030 mm) |
| Borderless print sizes |
Roll (25.4 cm), Roll (43.1 cm), Roll (60.9 cm), Roll (111.8 cm), Roll (91.4 cm) |
| Media thickness range |
0.1 mm - 1.5 mm |
| Media handling |
1 x manual - 1 roll - Roll (111.8 cm) |
| Network capabilities |
| Protocols and security features |
IPsec, AES-128, AES-256, LDAP, SSL, TLS, WPA3 |
| Expansion / Connectivity |
| Connections |
1 x USB 2.0
1 x Gigabit LAN - RJ-45 |
| Miscellaneous |
| Included accessories |
2 x maintenance boxes |
| Included supplies |
1 x ink cartridge (photo black)
1 x ink cartridge (matte black)
1 x ink cartridge (cyan)
1 x ink cartridge (yellow)
1 x ink cartridge (magenta)
1 x ink cartridge (grey) |
| Features |
Bluetooth interface, Trusted Platform Module (TPM), card authentication |
| Power |
| Power supply |
Power - internal |
| Required voltage |
AC 100-240 V |
| Required frequency |
50/60 Hz |
| Power consumption in operation |
70 Watts |
| Power consumption in standby mode |
0.3 Watts |
| Software / System requirements |
| Required operating system |
Apple macOS 11 or later, Apple MacOS X, Windows 10, Windows 11 |
| Manufacturer warranty |
| Service and support |
Limited warranty - 2 years - on-site |
| Environmental parameters |
| Noise emissions (operation) |
49.6 dBA |
| Dimensions and weight |
| Width |
184.8 cm |
| Depth |
82.9 cm |
| Height |
97.5 cm |
| Weight |
155 kg |
| Dimensions and weight (with packaging) |
| Depth (with packaging) |
198 cm |
| Height (with packaging) |
123 cm |
| Weight (delivery) |
203.48 kg |
