1" AC Electronic Irrigation Valve

1" AC Electronic Irrigation Valve

by Rainpoint
€19,90 - €19,90
€19,90
€19,90 - €19,90
€19,90
SKU DGT0442962
Ships within 7 business days Please note that quantities are limited and dynamic. At the time of ordering, the item may be out of stock. We will notify you in a timely manner in the event that we are unable to fulfill the order.

Избери период за изплащане и виж месечната вноска

Месечна вноска Обща сума за плащане ГПР Лихва Банка

Description

1" AC/DC Electronic Irrigation Valve

Ensure precise control of water flow in your irrigation system with the RainPoint 1” AC solenoid valve. The device operates on 24 V AC/DC, offering stable performance and fast response times thanks to a 250 mA inrush current and 15 mA holding current. A wide operating pressure range of 0.2–10 bar and a sealed IP68 design make the valve ideal for demanding installation conditions.

An open RainPoint® irrigation controller mounted on a wooden wall, connected by wires to four solenoid valves installed on a metal water manifold

Stable and efficient flow control

The valve can operate on both 24 V AC and 24 V DC, providing great flexibility in controller selection. This allows you to easily adapt it to an existing irrigation system or a new installation without being limited to a single power supply standard.

Technical diagram showing a black control panel connected by red and black wires to eight RainPoint® solenoid valves mounted on gray pipes

Compatibility with standard installations

The model is equipped with a 1” BSP connection, allowing for easy integration with popular irrigation systems. The standard thread enables quick installation and trouble-free connection to an existing garden system.

A black box buried in the lawn with an open green cover bearing the word "rain," inside which are four solenoid valves connected to pipes and the controller.

Durability in harsh conditions

The IP68-rated design ensures high resistance to moisture and water contact. The valve can operate at temperatures up to 60°C and across a wide pressure range, guaranteeing its durability and reliability even under intensive use.

Top view of the RainPoint® AC/DC Solenoid Valve with 24 Volt AC/DC specifications



Manufacturer RainPoint
Model BIV025ESC-AC
Connection diameter 1”
Operating voltage 24 V AC/DC
Inrush current 250 mA
Standby current 15 mA
Operating pressure 0.2–10 bar
Operating temperature up to 60°C
Protection rating IP68
