Avatto ZigBee smart bi-directional energy meter ZWPM16-1

Avatto ZigBee smart bi-directional energy meter ZWPM16-1

by Avatto
€12,90 - €12,90
€12,90
€12,90 - €12,90
€12,90
SKU DGT0306391
Ships within 8 business days Please note that quantities are limited and dynamic. At the time of ordering, the item may be out of stock. We will notify you in a timely manner in the event that we are unable to fulfill the order.

Избери период за изплащане и виж месечната вноска

Месечна вноска Обща сума за плащане ГПР Лихва Банка

Description

Avatto ZigBee ZWPM16-1 smart two-way energy meter

The Avatto ZigBee ZWPM16-1 smart two-way energy meter allows you to monitor your power consumption and production in real time. With a ZigBee connection, you'll get access to accurate hourly, daily, monthly and yearly statistics directly in the app, making it easy to analyze and plan savings for your home or office.

Black energy meter module with disconnected CT current sensor, shown on wooden surface

Accurate measurement and convenient operation

The Avatto ZWPM16-1 supports measurement from 0.2 to 80 amps and works with single-phase 100-240V installations. The precise CT sensor guarantees reliable results, and the data automatically synchronizes with the app for quick viewing of current and total energy consumption.

Energy meter connected to electrical switchgear with data read on smartphone screen

Compact form, easy installation

The device has compact dimensions, so it will easily fit into the switchboard. Installation is reduced to connecting the wires according to the markings. Robust housing made of flame-retardant PC plastic ensures safety and long life of the device.

Smartphone with energy monitoring app and a zoomed-in shot of the Wi-Fi energy meter module hidden behind the image

Included

  • Avatto ZigBee ZWPM16-1 smart energy meter
  • CT current sensor
  • User manual



Manufacturer Avatto
Model ZWPM16-1
Type single-phase
Operating voltage AC 100-240 V (50/60 Hz)
Measurement range 0,2-80 A
Communication ZigBee
Measurement type Bidirectional (energy consumption and production)
Module dimensions 38.8 × 38.5 × 40 mm
CT sensor dimensions 25.6 × 40 mm
Housing material PC flame retardant
Data in the application Hourly, daily, monthly, annual and total (kWh) measurement
