FAULT CURRENT PROTECTION 2P 40A 30MA AC ABB

The two-pole residual current device from ABB with a rated current of 40A and sensitivity 30mA is designed for effective protection against earth leakage currents in single-phase electrical installations. This type of protection safeguards both people from electric shock and property from the risk of fire caused by leakage.

Specifications:

Residual current type: Type AC
Rated short-circuit breaking capacity (Ics): 1 kA
Maximum surge current: 0.25 kA
Leakage current type: AC
Electrical endurance: 10000 cycles
Mechanical endurance: 20000 cycles
Number of poles: 2P
Number of DIN rail module spacings: 2
Operating characteristic: Instantaneous
Position of neutral terminals: Right
Rated cross-section:
4 - Multi-wire 10...25 mm²
1 - Single-wire 25...25 mm²
Rated voltage (Ur): 230/400 V
Rated operating voltage: 230 … 400 V AC
Rated insulation voltage (Ui): 500 V
Rated impulse withstand voltage (Uimp): 4 kV
Rated current (In): 40 A
Rated residual current: 30 mA
Rated conditional short-circuit current (Inc): 6 kA
Rated frequency (f): 50 Hz
Power loss: at rated operating conditions per pole 1.3 W
Number of modules: 2
Material compliance:
RoHS declaration: EU declaration of conformity_FH200
RoHS information: According to EU Directive 2011/65/EU and amendment 2015/863 of 22 July 2019
RoHS date: 20211115
REACH declaration: Reach declaration - ABB S.p.A. Vittuone
REACH information: True - contains substances > 0.1 mass percent
REACH date: 20240429
Conflict minerals reporting template (CMRT): Conflict minerals reporting template
SCIP: 719d39e9-c62c-4c41-a6dc-53de2a11e8ea Italy
WEEE category: 5. Small equipment (no external dimension more than 50 cm)
WEEE B2C / B2B:
Ambient air temperature:
Operation -5 ... +40 °C
Storage -40 ... +70 °C
Degree of protection: IP2X
Dimensions:
Width in number of module spacings: 4
Net product width: 70 mm
Net product height: 85 mm
Net product depth/length: 69 mm
Net product weight: 380 g
Installation depth (t2): 69 mm
