| Marketing description |
| NETGEAR M4350-12X12F is a powerful hub and switch designed to meet the needs of high-capacity networks. This device offers not only an impressive routing/switching capacity of 480 Gbps, but also supports a wide range of encryption algorithms that ensure your network remains protected from potential threats. With 24 versatile ports, including both 10GBase-T and SFP+ options, it provides the flexibility needed for various network configurations. The inclusion of a quad-core processor and 2 GB DDR4 SDRAM ensures the switch operates efficiently, even under heavy data traffic loads. Furthermore, its ability to support up to 4000 VLANs makes the switch a suitable choice for organisations that want to implement extensive network segmentation. NETGEAR M4350-12X12F is not just a switch; it is a strategic investment in the future of your network, offering reliability, security and scalability. |
| Product features |
-
Enhanced security
With support for 2048-bit RSA, 256-bit SHA-2, 512-bit SHA-2, MD5, SHA, SSL 3.0 and TLS 2.0 encryption algorithms, this switch ensures your network security is robust and resistant to unauthorised access and threats.
-
High-capacity networks
With a routing/switching capacity of 480 Gbps and support for up to 4000 VLANs, this device is designed to efficiently handle extensive networks, making it suitable for growing businesses.
-
Advanced connectivity options
Equipped with 24 ports, including 12 10GBase-T and 12 SFP+ ports, along with management interfaces and USB, this switch offers flexible connectivity options for a wide range of network configurations.
-
Reliable performance
With a quad-core processor clocked at 1.8 GHz and 2 GB DDR4 SDRAM, NETGEAR M4350-12X12F delivers reliable, high-speed performance for demanding network environments.
-
Efficient operation
With front-to-back airflow design, this switch maintains optimal operating temperatures up to 50 °C, ensuring stable performance and device longevity.
|
| General |
| Device type |
Switch - 24 ports - L3 - managed - stackable |
| Chassis type |
Front-to-back airflow, 1U rack-mountable |
| Subtype |
10 Gigabit Ethernet |
| Ports |
12 x 1/2.5/5/10GBase-T + 12 x SFP+ |
| Performance |
Routing/switching capacity: 480 Gbps Throughput (64-byte packet size): 357.12 Mpps Latency for 10 Gbps copper (64-byte packets): < 2.29 µs Latency for 10 Gbps optical fibre (64-byte packets): < 0.72 µs Latency (1 Gbps): < 2.14 µs |
| Capacity |
Packet buffer size: 32 MB Multicast entries (IPv4): 512 Multicast entries (IPv6): 256 Supported VLANs: 4000 Jumbo frame size: up to 12000 IGMP multicast groups: 2000 DHCP users: 2000 ARP entries: 4000 NDP entries: 512 |
| MAC address table size |
16K entries |
| Routing protocol |
Policy-based routing (PBR), RIP, VRRP, OSPF, PIM-DM, PIM-SM, PIM-SSM, IGMP, IGMPv3, MLDv2, RSTP |
| Remote management protocol |
SNMP 3, HTTPS, CLI, Telnet, SSH-2, MIB, RSTP, DHCP, RMON |
| Encryption algorithm |
SSL 3.0, TLS 2.0, 2048-bit RSA, 256-bit SHA-2, 512-bit SHA-2, SHA, MD5 |
| Authentication method |
TACACS, RADIUS, Secure Shell (SSH) |
| Features |
Jumbo frame support, LLDP-MED, RSPAN, PTPv2 TC support, MMRP, MVRP, BPDU, STRG, GMRP, GVRP, DAI, IP source guard, DHCPv4 server, DHCPv6 server, proxy ARP, sFlow, BOOTP support, ARP support, DoS attack prevention, DiffServ support, NSF, LACP, quad-core processor |
| Compatible standards |
IEEE 802.1as, IEEE 802.1Qav, IEEE 802.1Qat, IEEE 802.1ak |
| Processor |
1 x ARM Cortex-A57: 1.8 GHz |
| RAM |
2 GB DDR4 SDRAM |
| Flash memory |
512 MB |
| Expansion / connectivity |
| Interfaces |
12 x 10GBase-X SFP+ 12 x 10GBase-T RJ-45 1 x management (Gigabit LAN) RJ-45 2 x USB Type A 1 x console (USB) Type C |
| Power |
| Power supply |
Internal power supply |
| Installed quantity |
1 |
| Supplied power |
240 W |
| Power consumption in operating mode |
95.8 W |
| Power consumption in standby mode |
34 W |
| Miscellaneous |
| Included accessories |
Rubber feet, mounting brackets |
| Included cables |
1 x console cable |
| Rack mounting kit |
Included |
| Compliance with standards |
SCCP, IEEE 1588, AAA, AN/NZS 60950.1:2015, ANSI C63.4:2014, AS/NZS CISPR32:2013 Class A, BSMI CNS 13428, BSMI CNS 14336-1, CCC, CISPR 32:2012, EN 55024:2010, EN 55032:2012/AC:2013, EN 60950, EN 60950-1:2016+A11:2009+A1:2010+A12:2011+A2:2013, EN 61000-3-2 Class A, EN 61000-3-2:2014, EN 61000-3-3:2013, FCC CFR 47 Part 15 Class A, GB 4943.1-2011, GB/T9254-2008 Class A, GB4943.1-2001, ICES-003:2016 issue 6 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, ISED, RCM, UL 1950, VCCI-CISPR 32:2016 Class A, YD/T993-1998 |
| Localization |
Europe, North America, United Kingdom |
| Dimensions and weight |
| Width |
22 cm |
| Depth |
4.32 cm |
| Height |
40 cm |
| Weight |
9.48 kg |
| Manufacturer warranty |
| Service and support |
Limited warranty - lifetime |
| Environmental operating parameters |
| Min. operating temperature |
0 °C |
| Max. operating temperature |
50 °C |
| Operating humidity range |
90% (non-condensing) |
| Min. storage temperature |
-20 °C |
| Max. storage temperature |
70 °C |
| Storage humidity range |
95% (non-condensing) |
