TP-LINK Wireless Range Extender Dual Band RE190 AC750 White EU

Technical specifications:

Hardware Features:

• Connections: None specified
• Buttons: WPS Button, RESET Button
• Input Voltage: 100-240V~50/60Hz
• Power Consumption: 7.0W
• Dimensions (W x H x D): 110.0 x 65.8 x 38.8 mm
• Antenna: 3 Omni-directional Antennas

Wireless Features:

• Wi-Fi Standard:

  • IEEE 802.11a/n/ac 5GHz
  • IEEE 802.11b/g/n 2.4GHz
• Frequency: 2.4GHz and 5GHz
• Data Throughput:

  • 300Mbps at 2.4GHz
  • 433Mbps at 5GHz
• Operating Modes: Range Extender
• Reception Sensitivity:

  • 5GHz:

    • 11a 6Mbps: -94dBm
    • 11a 54Mbps: -78dBm
    • 11ac HT20 MCS0: -94dBm, MCS8: -73dBm
    • 11ac HT40 MCS0: -91dBm, MCS9: -65dBm
    • 11ac HT80 MCS0: -88dBm, MCS9: -62dBm
  • 2.4GHz:

    • 11g 54Mbps: -78dBm
    • 11n HT20: -75dBm
    • 11n HT40: -73dBm
• Wireless Features: WMM, Short GI, High Speed, WPS
• Wireless Security: WEP, WPA/WPA2-PSK encryptions
• Transmission Performance:

  • CE: <20dBm (2.4GHz)
  • <23dBm (5.15GHz~5.35GHz)
  • <30dBm (5.47GHz~5.725GHz)

Other Features:

• Certificates: CE, RoHS

Requirements:

• Microsoft Windows 98SE, NT, 2000, XP, Vista™, Windows 7, 8, 8.1, 10
• MAC OS, NetWare, UNIX or Linux
• Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser

Environment

• Operating Temperature: 0°C ~ +40°C
• Storage Temperature: -40°C ~ +70°C
• Operating Humidity: 10% ~ 90%RH
• Storage Humidity: 5% ~ 90%RH

Items included:

• Range Extender RE190
• Quick Installation Guide
